With Wide Range Of Filter Rating Sintered Filter Elements From 1um
- 100um
Sintered filter elements commonly are five-layer stainless steel
wire mesh superimposed and vacuum sintered. This type of sintered
filter element made with characteristics of strong corrosion
resistance, good permeability, high strength, easy cleaning and
high precision filtration accuracy, clean and sanitary filter
media, and no fiber dropping.
Features of Sintered filter elements:
Good strength and rigidity.
High precision and stable performance.
Corrosion resistance and heat resistanc.
Applications of Sintered filter elements:
Pharmaceutical Fields, Water treatment
Dust collection, Chemical Fiber
Foods And Beverage
Filtration Equipment
Applicable Typical Industries and Liquids
| Applicable industries | Fine chemicals, water treatment systems, pulp and
paper, auto industry, petro-chemical, machining, coatings,
electronics, etc. |
| Applicable liquids | Wide applicability, all liquids contained micro particles |
| Filtration function | Remove particles in various sizes, purify liquids, protect
key equipment |
| Filtration type | microfiltration, filter with disposable filter media, which
requires periodic manual replacement |
Performance of Sintered filter elements
1) Filter uniform and stable: the upper and lower layers as
protective mesh, coupled with the proliferation of solid melting of
the sintering process, the filter hole is not easy deformation, for
all the filtering accuracy can reach uniform filtration properties
for continuous and automation process.
2) Good strength: the reinforcement layer and the support layer do
support, with high mechanical strength and compressive strength.
3) Easy processing: for cutting, bending, stamping, drawing,
welding and other processing technology, easy to use.
4) The selection range is wide: You can use 316L, 304,321 and so
on.
5) Corrosion resistance: As a result of SUS316L 304 material, so
corrosion resistance, suitable pH environment filtering .
6) Extensive environment: Can be used temperatures of -200 ℃ ~ 600
℃.
7) Easy to clean: Since the shape of the mesh is fixed, uniform
pore size, combined with smooth and simple pore channels and
surface filter material is used, there is an easily cleaned (may be
countercurrent water, baking, etc. filtrate melting ultrasonic
cleaning method) can be used repeatedly, long life features.
